20 Gallon Water System for Camper Vans

Description

This water system for camper vans comes with everything needed to set up your wheel well water tank and connect it to your pump. The tank has a 20-gallon capacity and is compatible with Sprinters, ProMasters, and Transits.

***Tank may have excess plastic shards on the inside from the manufacturing process. We recommend to rinse out the tank before install to be sure.***

Features & Compatibility

• 20 Gallon capacity
• BPA-Free
• NSF/ANSI 61 Certified
• Reversible: For both driver and passenger sides.
• Naturally baffled to decrease water sloshing
• Centers weight over the axle
• 1/2 in FNPT Fittings on both ends of the tank and one on top.
• Threaded inserts on both ends of the tank (5/16"-18)
• Compatible with Sprinters, Transits, and ProMasters.
• Not compatible with dually trucks

Shipping

• Weight: 45 pounds
• Box Dimensions: 50 x 11 x 19 inches

• Processing time: 4–14 business days
• Shipping time: Up to 4 business days, depending on location

Kit Includes

• Wheel well water tank
• 12 feet of 3/8" ID braided vinyl tubing
• 6 feet of 5/8" ID braided vinyl tubing
• 1 - 3 way brass valve
• 1 - garden hose filler
• 4 - mounting brackets
• 1 - 3/8" barb elbow x 1/2" NPT
• 2 - 5/8" barb elbow x 1/2" NPT
• 2 - 5/8" barb x 1/2" NPT
• 2 - 1/2" NPT end caps
• 6 - 1" hose clamps
• 1 - 1/2" hose clamp

Specifications

• Capacity: 20 gallons
• Weight: 42 pounds
• Length: 50 inches
• Height: 19 inches
• Width: 11 inches
